Casambi Native Products
Explore the range of Casambi Native products — built for smart, wireless lighting control. Designed for seamless integration, these devices communicate directly via Bluetooth. Enjoy efficient, scalable, and intuitive lighting control for any environment.
The Casambi Cloud Gateway
Provides secure remote access and real-time monitoring of a Casambi Bluetooth mesh lighting network over the internet. It essentially extends all the control features available in the Casambi App to offsite access
The CBU-TED-LR
Bluetooth-controlled, long‑range trailing-edge dimmer developed by Casambi, designed to convert dimmable loads—such as incandescent, halogen, and dimmable LED lamps or drivers—into Casambi mesh network endpoints.
Input / Power
- Input voltage: 85–240 VAC, 50/60 Hz
- Max mains current: 0.43 A
- Standby power (no-load): < 0.3 W
Output / Load
- Dimming method : Trailing-edge phase control
- Max output power : 100W @ 230 VAC
- Max. output current: 0,43 A
- Min. load requirement: 1 W
Max. load inrush current: 10 A, 100 ms
The CBU-DCS-LR
The CBU‑DCS‑LR is a Bluetooth-enabled, long‑range DALI controller designed to integrate DALI-compatible LED drivers and sensors into a Casambi mesh network. Unlike analog modules, it does not include a power supply—it draws operating power from the DALI bus itself
Input :
- Voltage range: 9,5–22,5 VDC
- Input current when idle, Iidle: 5 mA
- Peak input current, Ipeak: 30 mA
- Max. DALI bus current: 250 mA
- Standby power: < 0,1 W
The CBU-ASD-LR
The CBU‑ASD‑LR is a long-range Casambi Bluetooth control unit that connects with LED drivers using analog (0–10 V or 1–10 V) and digital (Standalone DALI) dimming. When configured in Standalone DALI mode, it fully functions as both controller and DALI power supply—no external DALI bus needed—perfect for RGB, RGBW, or CCT applications with minimal wiring.
Input
- Voltage range: 220-240 VAC
- Frequency: 50Hz
- Max. mains current: 0,6 A
Mains Output
- Output relay: SSR on phase line
- Voltage range: 220-240 VAC
- Frequency: 50 Hz
**Risk of fire. Mains output is only allowed to connect to external relay. It
must not be connected to LED driver mains input.
0-10V Output
- Voltage range: 0-10 VDC
- Max. current: 6 mA
DALI Output
- Voltage range: 9-12 VDC
- Max. output current: 6 mA
The CBU-A2D
CBU-A2D is a Bluetooth controllable, Casambi enabled 2-channel 0-10V/DALI controller.
CBU-A2D can control one or two 0-10V controllable LED drivers, or it can control a tunable white LED driver with two 0-10V control interfaces. The product can also be configured into a DALI mode where it can be connected to a DALI LED driver or DALI sensor for presence and/or daylight harvesting functions.
With Standalone DALI output, CBU-A2D acts both as a controller and as a power supply making it possible to connect directly to an LED driver with DALI interface without the need for an external DALI power supply. This so-called Standalone DALI makes it possible to implement multi-channel lighting systems with adjustable color (RGB and RGBW) or color temperature (CCT), while keeping the wiring and number of components at their minimum.
Input
- Voltage range: 100-240 VAC
- Frequency: 50-60 Hz
- Max. mains current: 35 mA
- No-load standby power: < 0,5 W
Channel 1 output
- Output voltage, 0-10V: 0-10 VDC,
- max. 7 mA (sinking)
- Output voltage, DALI: 12 VDC, max. 20 mA (sourcing)
- Maximum number of drivers: 1 driver or 1 sensor/push button
Channel 2 output
- Output voltage, 0-10V: 0-10 VDC, max. 7 mA (sinking)
- Output voltage, relay control: 12 VDC, max. 100 mA (sourcing)
- Maximum number of drivers: 1
The CBU-PWM4-LR
CBU-PWM4-LR is a Bluetooth-controllable, four-channel PWM dimmer for constant voltage LED loads, such as LED strips and constant voltage LED modules. It is connected between a 12-24 VDC power supply and the constant voltage LED load
CBU-PWM4-LR can control up to four channels making it an ideal partner for RGBW and tunable white (TW) applications.
Input
- Voltage: 12–24 VDC, Class II
- Max. input current: 6,0 A
- No-load standby power: < 0,3 W
- Type of power supply: constant voltage
Output
- Output voltage: 12–24 VDC
- Max. output power: 144 W @ 24 VDC 72 W @ 12 VDC
- Max. output current: 6,0 A (can be freely divided between the channels)
- Min. load (recommended): 3 W (ref. to page 3)
- Load type: LED lights
- Dimming method: Pulse Width Modulation (PWM, freq. 400 Hz)
If you’re interested in making your lighting control smart or interested in purchasing any of the Casambi products, feel free to contact us — our team will be happy to assist you.
